8xIN+8xOUT (back order shipping July 4th)

Original price was: 79,90€.Current price is: 69,90€.

Unleash Full Audio I/O with the 8xIN+8xOUT for Raspberry Pi 5!

Take your Raspberry Pi 5 audio projects to the next level with the 8xIN+8xOUT, the all-in-one audio interface designed for ultimate flexibility. Building upon the success of our popular 8xOUT, this new HAT adds eight high-quality analog input channels, transforming your Raspberry Pi 5 into a powerful audio processing and streaming hub.

Whether you’re building sophisticated multi-zone audio systems, immersive home theaters, experimenting with spatial audio, designing custom active crossovers, or capturing multi-channel recordings, the 8xIN+8xOUT provides the comprehensive I/O you need. Simply plug it onto your Pi 5, enjoy automatic driver installation, and start streaming and capturing high-resolution audio across a total of sixteen channels!

Designed exclusively for Raspberry Pi 5.


Features

Inputs:

  • 8 channels of high-quality analog audio input via high-performance Analog-to-Digital Converters (ADCs).
  • Supports up to 192 kHz input sample rate for detailed audio capture.
  • 24-bit audio data resolution.
  • Excellent performance with a typical Signal-to-Noise Ratio (SNR) of 110 dB.
  • Standard 2.1 Vrms full-scale input, ideal for line-level sources.

Outputs:

  • 8 channels of high-quality analog audio output (4 stereo pairs) via four TI PCM5102A DACs.
  • Supports 16- to 32-bit audio data, up to 384 kHz output sample rate.
  • Impressive output performance:
    • Typical Signal-to-Noise Ratio (SNR): 112 dB
    • Total Harmonic Distortion + Noise (THD + N): –93 dB
  • Direct line-level output: 2.1 Vrms
  • Integrated high-performance audio PLL—auto-generates SCK from BCK.

Plug-and-Play & Connectivity:

  • Integrated EEPROM for automatic driver installation—no manual overlay edits required.
  • HAT-compliant: Auto-configures on your Raspberry Pi 5.
  • Designed exclusively for Raspberry Pi 5.
  • Includes 40-pin header riser, compatible with the official Raspberry Pi 5 case.
  • Male GPIO header on top—stack additional HATs without blocking access.
  • Compact form factor (65 × 56.5 mm), fits standard Pi 5 cases.







(Raspberry Pi and case not included)


Specifications

Parameter Input Value Output Value
Channels 8 TI ADC 8 (4 stereo pairs via 4 × PCM5102A DACs)
Chips TI ADC 4 × TI PCM5102A (Delta-Sigma with line driver)
Supported Data Formats I²S I²S, left-justified; 16-, 24-, and 32-bit audio
Sample Rate (max) Up to 192 kHz Up to 384 kHz
Resolution 24-bit 32-bit internal processing
SNR (typical) 110 dB 112 dB
THD + N (typical) TBD –93 dB
Voltage (Full Scale / Output) 2.1 Vrms 2.1 Vrms
Frequency Response 20 Hz – 20 kHz ± 0.1 dB (TBD) 20 Hz – 20 kHz ± 0.1 dB
Power Consumption < 0.5 W (TBD) < 0.3 W
Control Interface
Audio Interface 4xI²S 4xI²S
GPIO Header Standard 40-pin HAT header
Dimensions 65 × 56.5 × 35 mm
Weight ~ 45 g
EAN13 code : 3701488002964
